Benchmarks: Apple Silicon (M1 Max ARM64)
This page provides the empirical performance evaluation of Legolas++ on modern ARM64 architecture (Apple M1 Max, 8 Firestorm Performance Cores + 2 Icestorm Efficiency Cores, 64 GB Unified Memory, macOS 15).
📐 Physical Hardware Limits & Roofline Modeling
To understand why Legolas++ reaches these specific numbers and how close they are to the absolute physical limits of the silicon (Apple M1 Max 240–400 GB/s Unified Memory bandwidth and FMA vector issue pipelines), read the dedicated Roofline Performance Model & Hardware Efficiency Guide.
1. Tridiagonal Recurrence Benchmark (MultiThomas)
The benchmark evaluates the Thomas elimination algorithm solving \(N_y = N_x^2\) tridiagonal systems of dimension \(N_x \in [8, 512]\) (up to 262,144 systems, 134.2 million unknowns).
Throughput & Speedup Summary
| Configuration | Pack Size (\(P\)) | Cores | Throughput (\(N_x=512\)) | Peak Rate | Speedup |
|---|---|---|---|---|---|
| Scalar Sequential | \(P=1\) | 1 Core | 2.10 GFlops | 6.66 GFlops | 1.00x |
| Legolas NEON Native | \(P=4\) | 1 Core | 6.50 GFlops | 16.64 GFlops | 3.10x |
| Legolas NEON Unrolled | \(P=8\) | 1 Core | 9.58 GFlops | 16.64 GFlops | 4.75x |
| Scalar Multi-Thread | \(P=1\) | 8 Cores | 16.48 GFlops | 18.43 GFlops | 7.85x |
| Legolas NEON Multi-Thread | \(P=4\) | 8 Cores | 51.72 GFlops | 52.40 GFlops | 24.63x |
| Legolas Hybrid SIMD + Threads | \(P=8\) | 8 Cores | 69.15 GFlops | 69.40 GFlops | 33.05x |
2. Multi-Core Scaling Efficiency
Testing multi-core thread scaling from 1 to 8 threads on the Apple M1 Max Firestorm performance cores (\(P=8\) NEON unrolled, \(N_x = 512\)):
| Worker Threads | Measured Throughput | Speedup Factor | Parallel Efficiency |
|---|---|---|---|
| 1 | 9.58 GFlops | 1.00x | 100.0% |
| 2 | 19.04 GFlops | 1.99x | 99.4% |
| 3 | 28.52 GFlops | 2.98x | 99.2% |
| 4 | 37.59 GFlops | 3.92x | 98.1% |
| 5 | 46.22 GFlops | 4.82x | 96.4% |
| 6 | 54.49 GFlops | 5.69x | 94.8% |
| 7 | 62.46 GFlops | 6.52x | 93.1% |
| 8 | 69.15 GFlops | 7.22x | 90.2% |
3. Real-World Showcases Summary
| Workload / Domain | Metric | Scalar Baseline | Legolas NEON (M1 Max) | Speedup | Roofline Ceiling |
|---|---|---|---|---|---|
| MultiThomas Scientific Computing (Thomas) |
GFlops | 2.10 GFlops | 69.40 GFlops | 33.0x | 44.5% DRAM limit |
| Depthwise 2D Conv AI Vision (MobileNet) |
GFlops | 36.40 GFlops | 212.30 GFlops | 5.83x | 84.9% L2 cache |
| Audio IIR Biquad Audio DSP (64 Tracks) |
MSamples/s | 397.9 MS/s | 5,832.2 MS/s | 14.66x | 100% FMA issue |
| Video Pipeline (CPU) Vision / NVR (32 Feeds) |
FPS | 1,579.6 FPS | 8,442.1 FPS | 5.34x | Compute & L2 bound |
| Video Pipeline (Metal GPU) Vision / NVR (32 Feeds) |
FPS | 302.1 FPS | 17,263.9 FPS | 57.15x | 79.5% UMA bus |
Reproducing the Benchmarks Locally
# Build all showcase executables
cmake -B build
cmake --build build -j8
# Run the CPU showcases
./build/examples/DepthwiseConv
./build/examples/AudioBiquad
./build/examples/VideoPipeline
# Run Apple Silicon Metal GPU benchmark (macOS)
./build/examples/VideoPipelineMetal
# Run the MultiThomas benchmark suite
./build/tst/MultiThomas/MultiThomas
